✓ Basic Parameters ✓ Module: Module-Box 210CE ✓ External Dimensions: 5460 mm x 2000 mm x 2400 mm (L * W * H) ✓ Internal Dimensions: 5100 mm x 750 mm x 2100 mm (L * W * H) ✓ Rated Current: 4000 W (+10%) * 210 units ✓ Overall Color: White ✓ Weight: 1.9 T (-5% ~ +5 °/O) ✓ Electrical Appliance Certification: CE-CUL
Features
Maximum rated load：900kw/h Fuse protection：125A*20 sets Three-phase equilibrium：Each PDU is a sine wave with the same frequency, amplitude and phase difference of 120 degrees. Current protection: When the current flowing through the protected parts exceeds a pre-set value, the protection device starts and uses the time limit to ensure the selectivity of the action, so that the circuit breaker trips or gives an alarm signal.
Function
✔Loss of voltage protection:When the power is suddenly cut off due to some external reasons, the power can be cut off automatically;
✔Phase loss protection:When one phase of the three-phase power supply is disconnected, the three-phase equipment will reduce the output power and cannot work normally, or cause accidents. Therefore, some important equipment need to add phase loss protection device.
✔Undervoltage protection:refers to the action of the protection appliance when the line voltage is reduced to the critical level, and its task is mainly to prevent the equipment from burning up due to overload.
✔Automatic reclosing switch：It is a device that automatically re-closes the circuit breaker after it has been separated due to a fault, using a mechanical device or relay automatic device.
Remote System
✔ Global remote control, custom on/off schedule. ✔ Custom socket power usage record inquiry. ✔ Overall safety certification by China Classification Society. ✔ Overall CE certification/cUL safety certification. ✔ The power supply network is isolated from the miner network, eliminating background fee collection.
Item
Module Box V4
inner size （mm)
11000mm x 2100mm x 2860mm
outside size （mm)
12192mm x 2438mm x 2896mm
capacity
210 / 420 sets S19 pro
Standard
cULus / ETL
Operating power （kw)
540kw~830kw
Voltage/frequency
350V~480V AC 50~60Hz
master switch（A）
1260
Shelves
1100*400mm, 6 floors
switch （A）
16AC 420 pieces
Water curtain
16-32 pieces
Cold and hot isolation plate
9-18 pieces
Specification
Module Box-20HC
Module Box-40HC
External Sizes (mm)
6058 × 2438 × 2896
12192 × 2438 × 2896
Internal Sizes (mm)
5900 × 1380 × 2600
11800 × 1380 × 2600
Weight
4T (±5%)
8T (±5%)
Overall Volume (m³)
42.77
86.08
Shelf System
Internal Shelf Layers
2 × 6
4 × 6
Maximum Miners
210
420
Miner Model
S19Pro or others
S19Pro or others
Shelf Height (mm)
400
400
Adjustable Shelf Hole Distance (mm)
40
40
Power Supply System
Input Voltage
360 V – 480 V
360 V – 480 V
Module Output
200 V – 277 V, 50–60 Hz
200 V – 277 V, 50–60 Hz
Maximum Total Power
830 kW/h (3780 A)
1500 kW/h (6250 A)
PDU Power
3696 W/h (20 A)
3696 W/h (20 A)
Custom Switch
200 V – 280 V
200 V – 280 V
Intelligent PDU
200 V – 280 V
200 V – 280 V
Intelligent Server
200 V – 280 V
200 V – 280 V
Multi-Level Security Protection
Class 1 – Leakage Protector
Yes
Yes
Class 2 – Fuse Protector
Yes
Yes
Class 3 – Breaker Control Switch
Yes
Yes
Class 4 – PDU Independent Power Outage
Yes
Yes
Input Mode
3-Phase Equilibrium
3-Phase Equilibrium
Cooling System
Cooling Mode
Water Cooling Curtain, Miner Fan Heat Dissipation
Water Cooling Curtain, Miner Fan Heat Dissipation
Water Supply Pressure
≤ 1.5 Pa
≤ 1.5 Pa
Cold and Heat Isolation Panel
Waterproof, Flame-Retarded
Waterproof, Flame-Retarded
Dust Screen
Reduce Attachments
Reduce Attachments
Louver
Rainproof
Rainproof
Other Details
Intelligent Control System
The first inclusive network-based background interaction system
The first inclusive network-based background interaction system
